new

TE 50-AVR Rotary hammer

Name: TE 50-AVR Rotary hammer
Brand: Hilti
SKU: r4902202

3D animation of the corded rotary hammer TE 50-AVR showing measurements and weight of the tool.

Our most compact SDS Max (TE-Y) rotary hammer for lightweight comfort and control while drilling or chiseling in concrete, stone, and masonry

Weight according to EPTA-Procedure 01/2003 without battery: 6.1 kg
Weight class: 5 kg
Single impact energy: 6 J

Technical Data

Weight according to EPTA-Procedure 01/2003 without battery

6.1 kg

Weight class

5 kg

Single impact energy

6 J

Hammer drilling diameter range

12 - 82 mm

Optimum hammer drilling range

16 - 35 mm

Hammer drilling RPM

360 rpm

Full hammering frequency

3510 impacts/minute

Functionality

Active Vibration Reduction (AVR), Chiselling, Depth gauge

Triaxial vibration value for hammer drilling into concrete (ah,HD)

8.8 m/s² ¹

Dust removal system available

TE DRS-Y, TE DRS-D, TE DRS-BK

Triaxial vibration for chiselling in concrete

7.1 m/s² ²

Rated input power

1100 W

Dimensions (LxWxH)

449 x 115 x 272 mm

A-weighted emission sound power level

108 dB (A) ³

A-weighted emission sound pressure level

100 dB (A) ⁴

according to EN 62841-2-6
according to EN 60745-2-6
according to EN 60745
according to EN 60745

Documents

Features & Applications

Features

Exceptionally light and versatile SDS Max (TE-Y) rotary hammer
Low contact pressure for high user comfort
Active Vibration Reduction (AVR) makes the tool less tiring to use – helping to increase daily productivity
Optional DRS-Y dust removal system collects up to 95% of dust
Detachable supply cord for quicker and easier replacement of damaged/broken cords on the jobsite

Applications

Hammer drilling in concrete, masonry and natural stone (possible diameter range 12-55 mm, recommended diameter range 16-32 mm)
Light to medium-duty chiselling in masonry and concrete
Drilling penetrations mainly in masonry using percussion core bits (possible diameter range 45-150 mm, recommended diameter range up to 82 mm)
Hammer drilling in concrete, masonry and natural stone (possible diameter range 1/2"- 2", recommended diameter range 5/8" - 1 1/4")
Drilling penetrations mainly in masonry using percussion core bits (possible diameter range 1 3/4"- 5 15/16", recommended diameter range up to 3 1/4" )

For approval or certificate information, please see individual items.

Hilti Tool Service

Servicing is free of charge for up to 2 years, including wear and tear, pick-up and delivery
After the no-cost period, repair costs are capped
Product warranty against parts and manufacturing irregularities for as long as we service the tool
Product warranty against parts and manufacturing irregularities for 20 years
3-month no-cost period after each paid repair

More information about Tool Services

Fleet Management

Individual labels and online visibility provide tool fleet transparency
Monthly usage fee covering all tool, service and repair costs helping to ensure absolute cost control and back-office efficiency.
High-performing tools and latest technology help to increase jobsite productivity.
Loan tools during repair to reduce downtime.
Temporary tools for peak times and special applications help to reduce investments.

More information about Fleet Management

LifeTime Services

No repair costs for 2 years from date of purchase, including parts subject to wear and tear, shipping and labour
After the no-cost period, repair costs are capped for as long as we service the tool
1-month no-repair-cost period again after every paid repair
Materials and workmanship warranty over the entire life of the tool
Pick-up and delivery service

More information about LifeTime Services
