TE-YX (SDS Max) Metric hammer drill bit

Hammer drill bit TE-YX 32/92 #293410

Ultimate SDS Max (TE-Y) hammer drill bit for exceptional drilling performance in reinforced concrete (metric)

  • Connection end: TE-Y (SDS-max)
  • Base material: Reinforced concrete, Concrete, Masonry, Brick, Sand-lime block
  • Working mode: Hammer drilling, Drilling only

Customers also searched for drillingdrill bithigh drilling performancedemolition or tools & equipment.

Choose options

Diameter
  • 12 mm
  • 14 mm
  • 15 mm
  • 16 mm
  • 18 mm
  • 20 mm
  • 22 mm
  • 24 mm
  • 25 mm
  • 28 mm
  • 30 mm
  • 32 mm
  • 35 mm
  • 40 mm
Working length
  • 200 mm
  • 250 mm
  • 400 mm
  • 450 mm
  • 600 mm
  • 800 mm
  • 1150 mm
Length
  • 320 mm
  • 370 mm
  • 520 mm
  • 570 mm
  • 720 mm
  • 920 mm
  • 1300 mm
Pack size
  • 1 pc
  • 4 pc
Product options
Quantity
Packs
Total Piece
1
You can not see your company prices

Please Log in or register to see your company prices.

Price displayed for minimum order quantity:

4 Packs (Total pieces 4)

Discounted net
SR 6,592.00
SR 1,648.00 / 1 Piece

Technical Data

Connection end
TE-Y (SDS-max)
Base material
Reinforced concrete, Concrete, Masonry, Brick, Sand-lime block
Working mode
Hammer drilling, Drilling only
Head shape
Multi cutter
Head material composition
Tungsten carbide
Number of cutting edges
4
Diameter
32 mm
Length
920 mm
Working length
800 mm

Features & Applications

Features

  • Optimised multi-cutter (4 or 6-cutter) carbide head – superior drilling performance and less jamming when hitting rebar
  • Heat-treated flute offers superior wear resistance and maximum robustness, with a wear mark to estimate the bit's suitability for setting anchors
  • Slimmer and lighter helix for more comfortable drilling and superior drilling speed
  • Fully embedded drill bit head for maximum durability and longer life
  • In the unlikely event of breakage, the drill bit will be considered for replacement as long as the wear mark on the helix is still visible

Applications

  • Hammer drilling in reinforced concrete, concrete, masonry and other construction materials
  • Drilling holes for all chemical anchor installation purposes
  • Drilling anchor holes for all mechanical anchor installation purposes
  • Installing rebar using Hilti injectable adhesive mortar
  • Extra-long drill bits available for renovation work, e.g. sealing joints in masonry and concrete to prevent water penetration
