TE 70-AVR Rotary hammer

Very powerful SDS Max (TE-Y) rotary hammer for heavy-duty concrete drilling and chiselling, with Active Vibration Reduction (AVR)

Weight according to EPTA-Procedure 01/2003 without battery: 8.3 kg
Single impact energy: 11.5 J
Hammer drilling diameter range: 12 - 150 mm

Customers also searched for drilling holes, demolition, drilling in concrete and masonry, drilling in wood and steel or tools & equipment.

Choose options

Quantity

Packs

Total Pieces

You can not see your company prices

Please Log in or register to see your company prices.

Discounted net

Price loading error occured

Please contact us

Technical Data

Weight according to EPTA-Procedure 01/2003 without battery

8.3 kg

Single impact energy

11.5 J

Hammer drilling diameter range

12 - 150 mm

Optimum hammer drilling range

20 - 45 mm

Hammer drilling RPM

360 rpm

Full hammering frequency

2760 impacts/minute

Functionality

Active Vibration Reduction (AVR), Chiselling

Triaxial vibration value for hammer drilling into concrete (ah,HD)

10.8 m/s² ¹

Dust removal system available

TE DRS-Y, TE DRS-D, TE DRS-BK

Triaxial vibration for chiselling in concrete

9.0 m/s² ²

Rated input power

1800 W

Dimensions (LxWxH)

540 x 125 x 305 mm

A-weighted emission sound power level

113 dB (A) ³

A-weighted emission sound pressure level

105 dB (A) ⁴

according to EN 62841-2-6
according to EN 60745-2-6
according to EN 60745
according to EN 60745

Features & Applications

Features

Highest productivity for a wide range of drilling and chiselling applications
Low contact pressure for high user comfort
Active Vibration Reduction (AVR) makes the tool less tiring to use – helping to increase daily productivity
Optional DRS-Y dust removal system collects up to 95% of dust
Ruggedly built for a long lifetime

Applications

Hammer drilling in concrete, masonry and natural stone using bits in the 12-150 mm diameter range
Drilling holes for heavy-duty anchors from 20-40 mm in diameter
Breaching and demolition using pointed and flat chisels
Drilling with high torque in wood and steel
Hammer drilling in concrete, masonry and natural stone using bits in the 1/2" - 6" diameter range

For approval or certificate information, please see individual items.

Hilti Tool Service

3 or free: get the tool serviced and cleaned in 3 days flat or there is no charge
Servicing is free of charge for up to 2 years, including wear and tear, pick-up and delivery
After the no-cost period, repair costs are capped
Product warranty against parts and manufacturing irregularities for as long as we service the tool
Product warranty against parts and manufacturing irregularities for 20 years

More information about Tool Services

LifeTime Services

No repair costs for 2 years from date of purchase, including parts subject to wear and tear, shipping and labour
After the no-cost period, repair costs are capped for as long as we service the tool
1-month no-repair-cost period again after every paid repair
Materials and workmanship warranty over the entire life of the tool
Pick-up and delivery service

More information about LifeTime Services
