Weight according to EPTA-Procedure 01/2003 without battery: 5.5 kg
Optimum hammer drilling range: 16 - 35 mm
Hammer drilling diameter range: 12 - 82 mm

Technical Data

Weight according to EPTA-Procedure 01/2003 without battery

5.5 kg

Optimum hammer drilling range

16 - 35 mm

Hammer drilling diameter range

12 - 82 mm

Single impact energy

6 J

Hammer drilling RPM

360 rpm

Full hammering frequency

3510 impacts/minute

Functionality

Active Torque Control (ATC), Active Vibration Reduction (AVR), Chiselling, Hammer drilling

Triaxial vibration value for hammer drilling into concrete (ah,HD)

8.6 m/s² ¹

Triaxial vibration for chiselling in concrete

6.8 m/s² ²

A-weighted emission sound pressure level

99 dB (A) ³

A-weighted emission sound power level

107 dB (A) ⁴

according to EN 62841-2-6
according to EN 60745-2-6
according to EN 60745
according to EN 60745
